    IR2110PBF Integrated Circuit 600V High-Low Driver 2A Peak Current 10V-20V Logic 500ns Rise Time Package / Case 14-DIP (0.300", 7.62mm) -40°C to +125°C

    IR2110PBF


    Features

    • Floating channel designed for bootstrap operation Fully operational to +500V or +600V Tolerant to negative transient voltage dV/dt immune

    • Gate drive supply range from 10 to 20V

    • Undervoltage lockout for both channels

    • 3.3V logic compatible Separate logic supply range from 3.3V to 20V Logic and power ground ±5V offset

    • CMOS Schmitt-triggered inputs with pull-down

    • Cycle by cycle edge-triggered shutdown logic

    • Matched propagation delay for both channels

    • Outputs in phase with inputs


    Description

    The IR2110/IR2113 are high voltage, high speed power MOSFET and IGBT drivers with independent high and low side referenced output chan nels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. Logic inputs are compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. Propagation delays are matched to simplify use in high frequency applications. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 500 or 600 volts.


    Information

    Manufacturer
    Infineon Technologies
    Series
    -
    Packaging
    Tube
    Part Status
    Not For New Designs
    DigiKey Programmable
    Not Verified
    Driven Configuration
    Half-Bridge
    Channel Type
    Independent
    Number of Drivers
    2
    Gate Type
    IGBT, MOSFET (N-Channel)
    Voltage - Supply
    3.3V ~ 20V
    Logic Voltage - VIL, VIH
    6V, 9.5V
    Current - Peak Output (Source, Sink)
    2A, 2A
    Input Type
    Non-Inverting
    High Side Voltage - Max (Bootstrap)
    500 V
    Rise / Fall Time (Typ)
    25ns, 17ns
    Operating Temperature
    -40°C ~ 150°C (TJ)
    Mounting Type
    Through Hole
    Package / Case
    14-DIP (0.300", 7.62mm)
    Supplier Device Package
    14-DIP
    Base Product Number

    Drawing
